Zimmermann Formula Z Brake Disc, Front, Drilled | Porsche Panamera 970 Turbo (2009–2016)

Zimmermann Formula Z brake disc for the front axle of the Porsche Panamera 970 Turbo, Turbo S and GTS. The two-piece, floating composite brake disc is internally ventilated, drilled and coated. It is designed for high mechanical and thermal loads and replaces the standard brake disc 1:1, without any modification to the brake system.

Technical data

• Manufacturer: Zimmermann, Formula Z product line
• Design: two-piece, floating, internally ventilated, drilled, coated
• Outer diameter: 390 mm
• Brake disc thickness: 38 mm
• Bolt circle: Ø 130 mm
• Centring diameter: 98 mm
• Weight: 13.70 kg
• The floating mounting allows the friction ring to expand radially under high load, prevents coning and increases resistance to heat cracks
• Optimised ventilation channels against hot spots; less weight and therefore less unsprung mass
• 1:1 replacement for the standard brake disc, no adaptation of the brake system required

Scope of delivery

• 1 × brake disc, front (left or right, depending on selection)

Fits

• Porsche Panamera 970.1 Turbo 4.8 V8 (2009–2013)
• Porsche Panamera 970.1 Turbo S 4.8 V8 (2009–2013)
• Porsche Panamera 970.1 GTS 4.8 V8 (2011–2013)
• Porsche Panamera 970.2 Turbo 4.8 V8, including Executive (2014–2016)
• Porsche Panamera 970.2 Turbo S 4.8 V8 (2014–2016)
• Porsche Panamera 970.2 GTS 4.8 V8 (2014–2016)
• Only for vehicles with standard steel brake discs

Porsche reference numbers: 970 351 405 00, 970 351 406 00

Approval: Tested to ECE R90. No registration required: a general ABE certificate is supplied with the disc.

If you have any questions, we are happy to help.
